Embracing Thread-Per-Core Architecture

2026-01-27

What is "thread-per-core" ?

The term "thread-per-core" is confusing. It implies that there is one thread for each CPU core.

Aren't most modern multi-threaded async runtimes already following thread-per-core? Since most modern async runtimes use the M:N threading model. It spawns multiple N OS threads to handle M tasks concurrently.

However, the community refers to the term "thread-per-core" as a single-threaded runtime. Tasks are pinned to a specific thread.

Projects such as monoio, compio, and glommio are advertised as thread-per-core runtimes.

Why "thread-per-core" ?

Some algorithms only function correctly or work best in single-thread context. The task may use thread-local storage.

In this model, the tasks are pinned to a thread, which is a very powerful trait. The data is allowed to be mutated using a shared reference. Also, the CPU can execute more efficiently because data stays hot in the cache.

What I really like about this model is that the runtime doesn’t need any scheduler or synchronization.

In a traditional work-stealing runtime, such as Tokio require the task to be safe to Send across different threads in order to balance the workload.

Work stealing occurs only when a thread is idle. In practice, there are typically far more tasks than CPU cores, so threads almost always have some work to execute.

Announcing Nio v0.1.0 🎉

I’m pretty excited to announce the first stable release of Nio. It was completely rewritten from scratch.

[dependencies]
nio = { version = "0.1", features = ["tokio-io"] }

By default, Nio implements async traits from futures-io. But the optional "tokio-io" feature implements async traits from tokio::io.

Nio now support this folloing API.

nio::spawn_local

Spawn a !Send task that is pinned on the current thread.

let counter = Rc::new(Cell::new(0));
nio::spawn_local(async move {
  counter.update(|n| n + 1);
});

nio::spawn_pinned

Spawn a !Send task and pin it to a thread that has the least amount of work.

nio::spawn_pinned(|| async { ... });

Since we are spawning on a different thread. It accepts an async closure; captured variables have to be Send. However, the actual task itself does not need to be Send.

nio::spawn_pinned_at

Same as nio::spawn_pinned, but spawns the task pinned to a specific worker thread by its index.

nio::spawn_pinned_at(1, || async { ... });

nio::spawn

Spawn a new task. The task is not pinned to a worker thread and has to be Send. The runtime may move the task to a different thread at every .await point.

This is the same as tokio::spawn. Here is the benchmark. If you are curious how it compares to tokio::spawn.

The amazing part is that Nio supports all of these APIs without any config. There is no runtime flavor configuration either. Nio welcomes both “thread-per-core” folks and the rest of us.

Architecture

Under the hood, Nio uses a concurrent architecture called the Actor model.

Nio uses multiple worker threads to execute tasks. Each worker has a shared and local queue. The shared queue is used for:

  • Spawn a task on a different thread (nio::spawn_pinned, nio::spawn).
  • In cross-thread wakeup, the shared queue is also used to pin a !Send task to a specific worker thread.
  • If the task is spawned via nio::spawn, the runtime use shared queue to move the task to a different worker at every .await point.

The worker thread can access its local queue without any synchronization. However, the async API also needs to utilize the current thread runtime to avoid cross-thread wakeup. Consider this example:

let listener = TcpListener::bind("127.0.0.1:0").await?;
loop {
  // accept connection on thread `A`
  let mut socket = listener.accept().await?;
  nio::spawn_pinned(|| async move {
    // using tcp connection on thread `B`
    let _ = socket.read(..).await?;
  });
}

We accept tcp connection on worker A. Therefore, every TCP readiness happened on thread A, but the socket is waiting on thread B.

In other words, thread A wakes up a task that is waiting on thread B. This is not good, as it requires the use of shared queue synchronization. It destroys the benefit of using the so-called “thread-per-core” runtime in the first place.

let listener = TcpListener::bind("127.0.0.1:0").await?;
loop {
  let mut conn = listener.accept().await?;
  nio::spawn_pinned(|| async move {
    // accept connection on thread `B`
    let socket = conn.connect().await?;
    let _ = socket.read(..).await?;
  });
}

In this example, by using the connect() method, we bind the TCP connection on thread B, ensuring that all TCP readiness events occur on thread B instead of thread A.

To avoid cross-thread wakeup, Nio does not allow I/O resources (such as TCP connections or timers) to be moved between threads. In other words, I/O resources do not implement Send. This enables Nio to provide a highly efficient async API, as I/O resources can be implemented without atomic operations. This design really benefits the Timer implementation. Timer algorithms are inherently single-threaded. Nio timer doesn’t require any mutex lock.

A worker can be seen as an independent async runtime. In a sense, Workers do not share any state, reactor, and timer with each other.

The Nio project is broken into separate, smaller crates. So the community can benefit from it:
